Meanwell Power Outdoor DIP Led Display 6500 Nits Fixed Installation Epistar

China Meanwell Power Outdoor DIP Led Display 6500 Nits Fixed Installation Epistar supplier

Large Image :  Meanwell Power Outdoor DIP Led Display 6500 Nits Fixed Installation Epistar

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZFO10

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqms
Price: negotiation
Packaging Details: Plywood cartons
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 sqms per month
Contact Now
Detailed Product Description
LED: DIP346 RGB Chip: Epistar
Cabinet Size: 960*960mm Or 800*960mm Or Others Cabinet Materials: Steel Cabinet
Connector: Seetronic IC: MBI5124
Controller System: Linsn Control: By Computer Or U-disk Or Wifi Or Cloud Cluster Or Offline
Application: Street, Building, Shopping Mall

Meanwell Power Supplier 6500 nits Outdoor DIP Led Display Fixed Installation Epistar
Brief introduction:
Good Waterproof, Anti-UV
Driver board and Lamp board separate
Customized LED Screen size
1R1G1B Full color 14-16 bits
Moduler Panels
LED Chip Epistar Silan
Meanwell Power supplier
High reliable Waterproof Connector
Long lifetime, Easy to do maintance

Full color P10 high reliable full colour outdoor DIP led display can satisfy all kinds of demands of outdoor commercial digital media. And it is hotseller in past few years. Also new ideas are used onto it like AR, Interactive....

Currently P10 High reliable full colour outdoor DIP led display is the most popular in outdoor digital media application. It has advantages like customized display sizes, high definition, friendly user interface and multi-functional control methods.
P10 Outdoor fixed led display can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.
1. P10 High reliable full colour outdoor DIP led display, have the size of 960mm and 960mm or others.
2. The square shape product can be composed from the LED cabinet with the proportion of 16:9 and 4:3.
3. This LED cabinet only weighs 40kg and with depth of 100mm. That brings the benefits for the transportation.
4. The seamless design improves the display quality.
5. Featuring high resolution and high brightness, it can keep high contrast level even in strong sunlight.
6. The replace for modules costs few, without changing the original structure.
7. This unit cabinet offers a cost-effective display solution for outdoor usage.
8. Lamp board and driver board separate
P10 Outdoor DIP Led Screen

Pixel Pitch(㎜)10mm
Pixel Density(pixel/㎡)10000
Power supplierMeanwell
Panel Dimension(W×H)㎜320*160
Scan Mode1/4 1/2
Cabinet Dimension(W×H)㎜960*960
Warranty3 years
Color Temperature3200K-9500K
Viewing Angle(V)140°
Viewing Angle(H)140°
Contrast Ratio3000:1
Max Power Consumption(w/㎡)800
Ave Power Consumption(w/㎡)350
Operating Power SourceAC85~264V(47-63Hz)
Frame Frequency(Frame/S)60
Refresh Rate(Hz)≥1920
Gray LevelRGB65536Grade
Brightness Adjustment Level256Grade
Brightness Adjustment ModeManual/Automatic/Programmable
Control DistanceUTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp﹣20℃-﹢50℃
Operating Humidity10%-90%RH
Protecting RatingIP65
LED Life Span>100000h
LED Best View distance8m-300m

Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
