Product Details:
Payment & Shipping Terms:
|
| Led: | Nationstar Gold | Cabinet: | Steel |
|---|---|---|---|
| Chip: | Epistar Cree Nichia | Brightness: | >6500 Nits |
| IP: | IP65 | Control System: | Linsn |
| Control: | By Computer Or U-disk Or Wifi Or 3G 4G Or Offline | Support Distance: | CAT5 <100m , Fiber >100M |
| Display Content: | Texts,pics, Video | Application: | Street, Building, Shopping Mall,shops.. |
High Brightness 1/4 Scan 960*960mm Outdoor Led Advertising Screen Billboard Aluminum
Brief info:
Lamp board and driver board separate
Waterproof Neutrik connector
Can be Front maintenance, Front open
Module 320*160mm 160*160mm
P10 outdoor led screen 960*960mm or 960*800mm
Meanwell power supplier
3 - 5 years warranty
Epistar lamp Nationstar 8000nits
High brightness >6500nits or 8000nits
Fan cooling system
Currently P10 outdoor advertising led screen is the most popular in outdoor digital media application. It has advantages like customized display sizes, high definition, friendly user interface and multi-functional control methods.
RGB outdoor advertising led screen real pixel can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.
Full color P10 outdoor led video screens can satisfy all kinds of demands of outdoor commercial digital media. And it is hotseller in past few years. Also new ideas are used onto it like AR, Interactive....
RGB outdoor advertising led screen real pixel video display has DIP and SMD lamp, two soution. Each has its own advantages.
P10 Outdoor LED Display
| ITEM | P10 |
| Pixel Pitch(㎜) | 10 |
| Pixel Density(pixel/㎡) | 10000 |
| Pixel Component | 1R1G1B |
| LED Configuration | SMD3535 |
| Panel Dimension(W×H)㎜ | 320*160 |
| Scan Mode | 1/4 (or 1/2) |
| Cabinet Dimension(W×H)㎜ | 960*960/Customized |
| Cabinet Material | Iron/Customized |
| Brightness(cd/㎡) | ≥6000 ( or ≥7000) |
| Color Temperature | 3200K-9500K |
| Viewing Angle(V) | 140° |
| Viewing Angle(H) | 140° |
| Contrast Ratio | 3000:1 |
| Max Power Consumption(w/㎡) | 750 |
| Ave Power Consumption(w/㎡) | 300 |
| Operating Power Source | AC85~264V(47-63Hz) |
| Frame Frequency(Frame/S) | 60 |
| Refresh Rate(Hz) | ≥1200 |
| Gray Level | RGB65536Grade |
| Brightness Adjustment Level | 256Grade |
| Brightness Adjustment Mode | Manual/Automatic/Programmable |
| Control Distance | UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km |
| Operating Temp | ﹣20℃－﹢50℃ |
| Operating Humidity | 10%－90%RH |
| Protecting Rating | IP65 |
| MTBF | ＞10000h |
| LED Life Span | ＞100000h |
| LED Best View distance | ８m-３０0m |
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
