Product Details:
Payment & Shipping Terms:
|
Feature: | Magnetic Front Maintenance | Size: | 768*768mm |
---|---|---|---|
Grey: | 14-16bits | Cabinet: | Steel |
Control: | Wifi, Ipad, Computer, U-disk | Warranty: | 2 Years |
Brightness: | 1000-1500nits | Advantages: | Fanless |
Power Supplier: | Meanwell |
Classical design and natural tech., reliable quality and great performance.
Seamless connecting tech., screen flatness error <0.1mm.
Patented mask, eliminating the dark spots, improving consistency and viewing angle.
ITEM
|
Ph3
|
Pixel Pitch(㎜)
|
3mm
|
Pixel Density(pixel/㎡)
|
111111
|
Pixel Component
|
1R1G1B
|
LED Configuration
|
SMD2020 Nationstar
|
Panel Dimension(W×H)㎜
|
192*96 192*192
|
Scan Mode
|
1/32
|
Cabinet Dimension(W×H)㎜
|
768*768mm |
Cabinet Material
|
Steel |
Cabinet Weight(㎏)
|
50KG per sqm
|
Brightness(cd/㎡)
|
≥1000( Color Temperature6500K)
|
Color Temperature
|
3200K-9500K
|
Contrast Ratio
|
3000:1
|
Max Power Consumption(w/㎡)
|
1200
|
Ave Power Consumption(w/㎡)
|
480
|
Operating Power Source
|
AC85~264V(47-63Hz)
|
Frame Frequency(Frame/S)
|
60
|
Refresh Rate(Hz)
|
≥1920
|
Gray Level
|
RGB65536Grade
|
Brightness Adjustment Level
|
256Grade
|
Brightness Adjustment Mode
|
Manual/Automatic/Programmable
|
Control Distance
|
UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
|
Operating Temp
|
﹣20℃-﹢50℃
|
Operating Humidity
|
10%-90%RH
|
Protecting Rating
|
IP34
|
MTBF
|
>50000h
|
LEDLife Span
|
>100000h
|
LEDBest View distance
|
5m-150m
|
