Full Color SMD3528 Led Video Wall Screen , Fixed Installation Led Display

China Full Color SMD3528 Led Video Wall Screen , Fixed Installation Led Display supplier

Large Image :  Full Color SMD3528 Led Video Wall Screen , Fixed Installation Led Display

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZFI5

Payment & Shipping Terms:

Minimum Order Quantity: 1 squaremeter
Price: negotiation
Packaging Details: Flight case or Plywood
Delivery Time: 26-30 working days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Feature: Front&Rear Maintenance LED Chip: Epistar
Grey: 14-16bits Cabinet: Steel
LED: SMD3528 Nationstar Warranty: 2 Years
Brightness: 1000-1500nits Refresh: 1920HZ

Full color P5 SMD3528 Led Video Wall Fixed Installation Screen for Conference​
P5 indoor screen Quick details
Contrast 3000:1 Grey 14-16bits
Cabinet size customized (720p,1080P)
Nationstar led lamp SMD3528
MBI Ic from Taiwan
Meanwell power supplier 5V 60A
CE & UL certifications
Magnetic front maintenance led screen

Classical design and natural tech., reliable quality and great performance.

Seamless connecting tech., screen flatness error <0.1mm.

Patented mask, eliminating the dark spots, improving consistency and viewing angle.

PCB 1.6mm Thickness 4 layers
1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
Low Cost of Splicing
With an aspect ratio of 16:9, panel size is carefully designed so that the HD LED display can be assembled quickly and efficiently into the common display ratio of 4:3 or 16:9
Indoor fixed led screen has many kinds of installation, like front open design, magnetic led panel design. It can be used all kinds shopping malls, night clubs, conference and so on.
P5 Indoor Led Screen
Pixel Pitch(㎜) 5mm
Pixel Density(pixel/㎡) 40000
Pixel Component 1R1G1B
LED Configuration SMD3528 Nationstar
Panel Dimension(W×H)㎜ 320*160
Cabinet Material Steel
Cabinet Weight(Kg) 50KG
Brightness(cd/㎡) ≥1200
Color Temperature 3200K-9500K
Viewing Angle(V) 140°
Viewing Angle(H) 140°
Contrast Ratio 3000:1
Max Power Consumption(w/㎡) ≤800
Ave Power Consumption(w/㎡) ≤480
Operating Power Source AC85~264V(47-63Hz)
Frame Frequency(Frame/S) 60
Refresh Rate(Hz) ≥1200
Gray Level RGB65536Grade
Brightness Adjustment Level 256Grade
Brightness Adjustment Mode Manual/Automatic/Programmable
Control Distance UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp ﹣20℃-﹢50℃
Operating Humidity 10%-90%RH
Protecting Rating IP31
MTBF >50000h
LED Life Span >100000h

Pre-sale service:
1. Reply enquiries in 16 hours.
2. Provide unique and professional solutions based on customer's requirement.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
