Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits

Good quality Led Video Screen Rental for sales
Good quality Led Video Screen Rental for sales
Zhongyi is a trusted and professional supplier I have ever met.Thanks so much for your help to deal with my last urgent order.

—— Michael

I have bought twice from Andy, and the quality is great. Hope you guys can be better and better.

—— Dinesh

Good service!At one time,my flight case have crashed when shipping, thanks for doing maintenance and renew our screens.

—— Mohammed

I'm Online Chat Now

Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits

China Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits supplier
Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits supplier Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits supplier

Large Image :  Static Full color P16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZF16

Payment & Shipping Terms:

Minimum Order Quantity: 1 squaremeter
Price: negotiation
Packaging Details: Plywood cartons
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Scan: Static Pixel Pitch: 16mm
Connector: Seetronic Warranty: 2 Years Or Longer
Power Supplier: Meanwell Brightness: 6500nits
Voltage: 100-24V Weight: 48kg Per Sqm
LED: 1R1G1B

Static Full color p16 Outdoor Led Video Screen Advertising Billboard RGB 6500nits


P16 Rgb Led Video wall Solutions
Specifications

High Brightness, Brightness adjust automatically
Meanwell Power supplier, Seetronic Connector

Meanwell power supplier
2 Years warranty

Brief introduce:
1.Ultra bright LED lamp Nationstar, and the best raw materials to made into plastic parts.
2.Chip encapsulation uses pure golden wire to solder, red chip encapsulation uses double pure golden wires to keep stability. Led Chip Epistar Nichia Cree
3.The copper silvering trestle.
4.High-end specialized outdoor glue.
5.Brushing black lamp with five surface and black gluing to keep the uniformity of screen.
6.Plated signal and power connector.
7.Pure-copper environmental flat cable,pure-copper power wire.


Feature
1. Classic module design, superior product performance, stability.
2. Uniform color, high contrast, beautiful natural picture.
3. New perspective optimization design, covering the mainstream audience.
4. Anti UV, anti deformation module suite to protect the screen body deformation.
5. Patent design with unique color mask processing, showing the industry leading ultra high contrast.
6. Multiple waterproof casing design, single box full inspection factory, the protection level IP65 mature signal transmission architecture, equipped with the upgraded version of power management technology, the use of more secure and reliable.
7. Patent design with unique color mask processing, showing the industry leading ultra high contrast.
8. Ultra low temperature free fan design, low temperature rise, small attenuation, long service life.

Advantage
High quality LED chip and high anti-static electricity capacity.
Large viewing angle and smooth displaying provide excellent visual effect from every angle.
The integration of lamp and driving IC, together with with the multi-circuit structure, achieves evenly-distributed current, low power consumption and fast heat dissipation.
Ultra-high brightness, low attenuation, high reliability and weather ability.

P16 Waterproof outdoor led video screen can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.


Specification parameter
P16 LED Video screen Specifications

ITEMP16
Pixel Pitch(㎜)16
Pixel Density(pixel/㎡)3906
Pixel Component1R1G1B Full color
LED ConfigurationDIP346
Panel Dimension(W×H)㎜256*128 320*320
Scan ModeStatic
Cabinet Dimension(W×H)㎜1024*1024
MaintenanceRear
Brightness(cd/㎡)≥6500
Color Temperature3200K-9500K
Viewing Angle(V)120°
Viewing Angle(H)60°
Contrast Ratio125.0006944
Max Power Consumption(w/㎡)≤750
Ave Power Consumption(w/㎡)≤300
Operating Power SourceAC85~264V(47-63Hz)
Frame Frequency(Frame/S)60
Refresh Rate(Hz)≥1920
Gray LevelRGB65536Grade
Brightness Adjustment Level256Grade
Brightness Adjustment ModeManual/Automatic/Programmable
Control DistanceUTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp﹣20℃-﹢50℃
Operating Humidity10%-90%RH
Protecting RatingIP65
MTBF>10000h
LED Life Span>100000h
LED Best View distance10m-300m



Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
