Product Details:
Payment & Shipping Terms:
|
| Lamp: | DIP Or SMD | Connector: | Reunion |
|---|---|---|---|
| Installation: | Tool-free | Work Temprature: | -35℃ -- -80℃ |
| Brightness: | 6500nits | Weight: | 15kg Per Sqm |
| Cooling: | Natural Convection | Material: | Fire Resistant |
Transparency 40% 6500nits P15-31 Outdoor Fixed Led Display Curtain -40 ~+85°C
Quick introduction:
Pixel Pitch: Horizontal 15.6mm Vertical 31.25mm
Fire resistant material Innovation
Brightness Adjust automatically
Cost savings 70% of steel structure
Cost savings 80% of labour
Cost savings 75% of transportation
Cost savings 80% of maintain operation
Cost savings 70% of electricity
Cost savings of Air conditioner
Brief info:
Fire resistant material
-40℃ -- +80℃
80% heat sinking
IP65
No fan design, low temperature operation, quiet no noise
Ultra-thin box, easy to transport, installation and maintenance
Support front and rear maintenance, installation more convenient
Low power consumption, low heat, energy saving and environmental protection
Signal, power supply stability, the use of safe and reliable
Efficient and stable, high reliability, long service life
Special only led Grid Screen
Steel weight 10KG/sqm only, equal 15% of traditional outdoor led screen steel Cabinet
Transparency 40%-80%
Look like Screenless
Quick installation
Finish installation 10 seconds per sqm
Fast maintenance
Patented design for 3 minutes/sqm
Easy to achieve front / rear maintenance
Specification parameter P15.6 outdoor Led Curtain Fixed led Display
| Tube color | Specifications | Indicators (typical values, specific to selected lamps) |
| R | domestic | Wavelength: 618-630nm, brightness 870mcd (20mA) |
| G | domestic | Wavelength: 518-538nm, brightness 1680mcd (10mA) |
| B | domestic | Wavelength: 460-480nm, brightness 380mcd (10mA) |
| Product model | 15mm-31mm |
| Horizontal spacing(mm) Vertical spacing(mm) | 15.625mm 31.25mm |
| Pixel composition | DIP346 |
| Resolution (dot/㎡) | 4096 |
| Unit cabinet dots | 2048 |
| Pixel per Unit(dots) | 32(W)x64(H) |
| Color Grayscale (Bit) | 14 |
| Brightness(CD/㎡) | ≥6500cd |
| Contrast | 1:1600 |
| Color temperature | 6500-9300k |
| (Brightness adjust) | 0-255 |
| Horizontal viewing angle(°) Vertical viewing angle(°) | ≥110° ≥50° |
| The best viewing distance(M) | 15-300 |
| Max Consumption(W/㎡) | 450 |
| Average power consumption(W/㎡) | 135 |
| Unit cabinet Weight (kg/pcs) | 10.0 |
| Cabinet Weight (kg/㎡) | 20.0 |
| Frame Weight (kg/㎡) | 8.0 |
| Unit cabinet thickness (cm) | 6.7 |
| Frame thickness (cm) | 6.0 |
| Installation thickness (cm) | 12.7 |
| Strips width(mm) | 9.8 |
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
