Power Supplier: | Greatwall CE | Power: | 5V 60A |
---|---|---|---|
Refresh: | 2880HZ Or 3840HZ | Led Chip: | Epistar Silan |
LED Lamp: | SMD2020 Or SMD1515 | IC: | MBI5153 |
Warranty: | 2 Years Or Longer | Connector: | Neutrik Or Seetronics |
Cabinet Materials: | Die-casting | Cabinet Weight: | 7.5 Kg Per Piece |
Packing: | Flight Case | IP: | IP30 |
Lifetime: | 100,000hours |
2.6mm High Resolution UHD Led Display Video Wall Solution Colorful Grey Scale 4K Large TV
Advantages:
Eliminate ghost, light staying and noise, accurate color rendition;
Excellent low-brightness-grayscale performance and great degree of linearity, make your picture fine and smooth;
No color temperature deviation between LED modules, High-contrast display;
System Pulse-Width Modulation (PWM), High refresh rate and large 16 bits grayscale;
Fast output response, 20 ns minimum Output Enable (OE) duration;
Lower power dissipation on LED display, energy saving up to 35%; Lower the temperature of module front by 5 degree Celsius;
0.6 ~ 45 mA (6V) high-accuracy constant current output;
Smart output control, lower Electromagnetic Interference (EMI);
Excellent output current matching accuracy: dot to dot: <±3.0% (Max), Chip to Chip: <±6.0% (Max);
Low Diode Knee Voltage, 0.4 V;
Max data clock frequency: 35 MHz;
Schmitt trigger input;
Main Features:
1. Die-casting aluminum, lightweight yet sturdy. Cabinet size: 500x500, 8KG
2. Front and rear serviceable, fast assembly and disassembly, hanging supportive;
3. Replaceable plug-in power supply box, easy to change
4. Big screen, small screen, no limits at size of video wall
5. Compatible for various signal sources, for example, AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI,DP
Pixel pitch
|
2.6mm
|
Pixel configuration
|
SMD1515
|
Pixel resolution
|
192*192dots/panel
|
Pixel density
|
147456dots/㎡
|
Panel size
|
500*500mm
|
Panel weight
|
8KG/panel
|
Panel material
|
die-cast aluminum
|
Modules per panel
|
4 modules/panel
|
Brightness
|
1000~1200nits
|
Refresh rate
|
1920Hz~2880Hz
|
Gray scale / display color
|
16bit
|
Contrast ration
|
4000/1
|
Viewing angle
|
140° H, 140° V
|
LED life expectancy
|
100,000 hours
|
Warranty period
|
3 years
|
Maintaince
|
Module front service
|
