Product Details:
Payment & Shipping Terms:
|
Contrast: | 4000:1 | Refresh: | 3000HZ |
---|---|---|---|
Size: | 500*500 | Led Chip: | Epistar Silan |
LED Lamp: | SMD2020 Or SMD1515 | IC: | MBI5153 |
Warranty: | 2 Years Or Longer | Connector: | Neutrik Or Seetronics |
Cabinet Materials: | Die-casting | Cabinet Weight: | 7.5 Kg Per Piece |
Packing: | Flight Case | IP: | IP30 |
Lifetime: | 100,000hours |
2.6mm High Resolution UHD Led Display Video Wall Solution Colorful Grey Scale 4K Large TV
P2.6mm HD led screen
6 layers Thickness 2mm PCB
Gold wire lamp
Taiwan MBI5124 IC PMW
Reliable Quality
Advantages:
Eliminate ghost, light staying and noise, accurate color rendition;
Excellent low-brightness-grayscale performance and great degree of linearity, make your picture fine and smooth;
The LED Display screens are in modular 500x500mm panels. These panels lock together and create any size screen that fits your needs.
We have advanced video processing equipment to handle all your input
needs. HDMI, DVI, VGA, S-VIDEO, COMPONENT +COMPOSITE accepted.
Mac, PC, PowerPoint, Cameras, and live VJ input are no problem!
No color temperature deviation between LED modules, High-contrast display;
System Pulse-Width Modulation (PWM), High refresh rate and large 16 bits grayscale;
Fast output response, 20 ns minimum Output Enable (OE) duration;
Lower power dissipation on LED display, energy saving up to 35%; Lower the temperature of module front by 5 degree Celsius;
0.6 ~ 45 mA (6V) high-accuracy constant current output;
Smart output control, lower Electromagnetic Interference (EMI);
Excellent output current matching accuracy: dot to dot: <±3.0% (Max), Chip to Chip: <±6.0% (Max);
Low Diode Knee Voltage, 0.4 V;
Max data clock frequency: 35 MHz;
Schmitt trigger input;
Main Features:
1. Die-casting aluminum, lightweight yet sturdy. Cabinet size: 500x500, 8KG
2. Front and rear serviceable, fast assembly and disassembly, hanging supportive;
3. Replaceable plug-in power supply box, easy to change
4. Big screen, small screen, no limits at size of video wall
5. Compatible for various signal sources, for example, AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI,DP
Pixel pitch
|
2.6mm
|
Pixel configuration
|
SMD1515
|
Pixel resolution
|
192*192dots/panel
|
Pixel density
|
147456dots/㎡
|
Panel size
|
500*500mm
|
Panel weight
|
8KG/panel
|
Panel material
|
die-cast aluminum
|
Modules per panel
|
4 modules/panel
|
Brightness
|
1000~1200nits
|
Refresh rate
|
1920Hz~2880Hz
|
Gray scale / display color
|
16bit
|
Contrast ration
|
4000/1
|
Viewing angle
|
140° H, 140° V
|
LED life expectancy
|
100,000 hours
|
Warranty period
|
3 years
|
Maintaince
|
Module front service
|
