Product Details:
Payment & Shipping Terms:
|
| Cover: | Transparent PC | Pixel Pitch: | 8.9mm |
|---|---|---|---|
| Led: | SMD3535 Nationstar | Power Supplier: | Meanwell |
| Voltage: | 100-240v | Size: | 500*1000mm |
| Brightness: | 4000nits | Refresh: | 1920 HZ Or 2880 HZ Or 3840HZ |
| Weight Bearing: | 1800KG Per Sqm |
Outdoor Epistar Chip SMD3535 Nationstar Led dance floor Video 500*1000mm Aluminum
Introduction:
High bearing:Cabinet made from die cast aluminum material,stronger and lighter.1800kg/sqm weight loading.
IP65:Anti-water,Anti-drinks spill.
Friendly maintainence:No need to disassembly the cabinets nearby when changing a cabinet.Much more easier for mantainence.
High contrast ratio:Patented mask design makes clear images.
Excellent cooling design:Professional cooling design,ensure a perfect heat dissipation.
Details:
1. Led video dance floor special effects in the stage performance have been used most vividly, to create a magnificent, very modern scene and give us the immersive audio-visual feast.
Feature
1. unified standard design for Signal lines and power lines
2. LED lamp beads bracket with pure copper bracket, red light 12MIL, blue and green 13MIL
3. PC cover with anti-skid treatment
4. Ultra-high brightness LED lamp beads and top A grade plastic cover.
5. High-end LED display dedicated waterproof silicone.
6. exclusive line design Printed Circuit Board
| Pixel pitch(mm) | 8.9 |
| Pixel configuration | SMD3535 |
| Weight bearing | 1.5ton per sqm |
| Cabinet size(W*H*D mm) | 500×500×70 |
| Pixel Density(Pixels/㎡) | 12,544 |
| Brightness(cd/㎡) | 3000≤&≤4000 |
| Cabinet Material | Aluminum |
| Cabinet weight(kg) | ≈11kg |
| Input Power Frequency(Hz) | 50/60 |
| Input voltage(Nominal)(V) | 220V(110/110-220) |
