Anti - Wind Grid Billboard Advertising Led Display Screen 6000 Nits 1R1G1B

Good quality Led Video Screen Rental for sales
Good quality Led Video Screen Rental for sales
Zhongyi is a trusted and professional supplier I have ever met.Thanks so much for your help to deal with my last urgent order.

—— Michael

I have bought twice from Andy, and the quality is great. Hope you guys can be better and better.

—— Dinesh

Good service!At one time,my flight case have crashed when shipping, thanks for doing maintenance and renew our screens.

—— Mohammed

I'm Online Chat Now

Anti - Wind Grid Billboard Advertising Led Display Screen 6000 Nits 1R1G1B

China Anti - Wind Grid Billboard Advertising Led Display Screen 6000 Nits 1R1G1B supplier

Large Image :  Anti - Wind Grid Billboard Advertising Led Display Screen 6000 Nits 1R1G1B

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZF31

Payment & Shipping Terms:

Minimum Order Quantity: 1 squaremeter
Price: negotiation
Packaging Details: Plywood cartons
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Support: Video Pictures Texts Resolution: 1024
Warranty: 2 Years Or Longer Work Temprature: -35℃ -- -80℃
Brightness: 6000nits Control: Brightness Adjust
IC Brand: MBI Control System: Ydea
Maintenance: Front & Rear Maintenance

Anti-Wind P31.25 1R1G1B Grid Billboard Advertising Led Display Screen 6000 nits in -35℃ low temperature
Brief info:
Transparency 40%-80%
Look like Screenless
Reunion Connector
Low temperature power supplier
Signal, power supply stability, the use of safe and reliable
Efficient and stable, high reliability, long service life
No fan design, low temperature operation, quiet no noise
Ultra-thin box, easy to transport, installation and maintenance
Support front and rear maintenance, installation more convenient
Low power consumption, low heat, energy saving and environmental protection
Fast maintenance
Patented design for 3 minutes/sqm
Easy to achieve front / rear maintenance
Special only led Grid Screen
Steel weight 10KG/sqm only, equal 15% of traditional outdoor led screen steel Cabinet
Quick installation
Finish installation 10 seconds per sqm
Quick introduction:
Cost savings of Air conditioner
Cost savings 80% of maintain operation
Cost savings 70% of electricity
Cost savings 70% of steel structure
Cost savings 80% of labour
Cost savings 75% of transportation

Specification parameter P31.25 outdoor Led Curtain Fixed led Display

Tube colorSpecificationsIndicators (typical values, specific to selected lamps)
RdomesticWavelength: 618-630nm, brightness 870mcd (20mA)
GdomesticWavelength: 518-538nm, brightness 1680mcd (10mA)
BdomesticWavelength: 460-480nm, brightness 380mcd (10mA)
Product model31.25mm-31.25mm
Horizontal spacing(mm) Vertical spacing(mm)31.25mm 31.25mm
Pixel compositionDIP346
Resolution (dot/㎡)4096
Unit cabinet dots1024
Pixel per Unit(dots)32(W)x32(H)
Color Grayscale (Bit)14
Color temperature6500-9300k
(Brightness adjust)0-255
Horizontal viewing angle(°) Vertical viewing angle(°)≥110° ≥50°
Max Consumption(W/㎡)450
Average power consumption(W/㎡)135
Unit cabinet Weight (kg/pcs)10.0
Cabinet Weight (kg/㎡)20.0
Frame Weight (kg/㎡)8.0
Unit cabinet thickness (cm)6.7
Frame thickness (cm)6.0
Installation thickness (cm)12.7
Strips width(mm)9.8
Transparent Rate(%)40%
Frame rate(HZ)60
Pixel uncontrol rate<1/10000

Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
