Fixed Indoor Led Video Wall Screen , HD Video Wall Die - Casting Aluminum P3

: Large Image : Fixed Indoor Led Video Wall Screen , HD Video Wall Die - Casting Aluminum P3

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Zhongyi
Certification:	CE / RoHS / FCC / ETL / TUV
Model Number:	ZFI

Payment & Shipping Terms:

Minimum Order Quantity:	1 squaremeter
Price:	negotiation
Packaging Details:	Flight case or Plywood
Delivery Time:	26-30 working days after received prepayment
Payment Terms:	30% T/T prepayment, 70% T/T balance before shipment
Supply Ability:	3000 squaremeters per months

Contact Now

Detailed Product Description

Led:	Epistar Lamp Nationstar	Size:	768*768mm 960mm
Installation:	Hanging, Stacking	Cabinet:	Steel Or Aluminum
Control:	Wifi, Ipad, Computer, U-disk	Warranty:	2 Years
Brightness:	1000-1500nits	Refresh:	1920HZ

High Grey High Refresh Indoor Fixed Led Video Wall Screen Vivid video for Conference

Quick details

PCB 1.6mm Thickness 4 layers

P3 led screen modules 192*192mm 192*96mm
Cabinet size 768*768mm or customized (720p,1080P)
Nationstar led lamp SMD2020
MBI Ic from Taiwan

Meanwell power supplier 5V 60A
CE & UL certifications
Brightness:>1000nits

1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.

Low Cost of Splicing
With an aspect ratio of 16:9, panel size is carefully designed so that the HD LED display can be assembled quickly and efficiently into the common display ratio of 4:3 or 16:9

Indoor fixed led screen has many kinds of installation, like front open design, magnetic led panel design. It can be used all kinds shopping malls, night clubs, conference and so on.

P3 Indoor Led Screen

ITEM	P3
Pixel Pitch(㎜)	3mm
Pixel Density(pixel/㎡)	111111
Pixel Component	1R1G1B
LED Configuration	SMD2121
Panel Dimension(W×H)㎜	*19296 192192*
Scan Mode	1/32
Cabinet Dimension(W×H)㎜	768*768mm
Cabinet Material	Die-casting Aluminum
Cabinet Weight(㎏)	50KG per sqm
Brightness(cd/㎡)	≥1000( Color Temperature6500K)
Color Temperature	3200K-9500K
Viewing Angle(V)	120°
Viewing Angle(H)	140°
Contrast Ratio	3000:1
Max Power Consumption(w/㎡)	1200
Ave Power Consumption(w/㎡)	480
Operating Power Source	AC85~264V(47-63Hz)
Frame Frequency(Frame/S)	60
Refresh Rate(Hz)	≥1920
Gray Level	RGB65536Grade
Brightness Adjustment Level	256Grade
Brightness Adjustment Mode	Manual/Automatic/Programmable
Control Distance	UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km
Operating Temp	﹣20℃－﹢50℃
Operating Humidity	10%－90%RH
Protecting Rating	IP34
MTBF	＞50000h
LEDLife Span	＞100000h
LEDBest View distance	5m-150m

Pre-sale service:
1. Reply enquiries in 16 hours.
2. Provide unique and professional solutions based on customer's requirement.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
