P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum

Good quality Led Video Screen Rental for sales
Good quality Led Video Screen Rental for sales
Zhongyi is a trusted and professional supplier I have ever met.Thanks so much for your help to deal with my last urgent order.

—— Michael

I have bought twice from Andy, and the quality is great. Hope you guys can be better and better.

—— Dinesh

Good service!At one time,my flight case have crashed when shipping, thanks for doing maintenance and renew our screens.

—— Mohammed

I'm Online Chat Now

P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum

China P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum supplier
P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum supplier P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum supplier

Large Image :  P8 640 * 640 MM Outdoor Led Screen Hire 6500 Nits Die - casting Aluminum

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE ROSH FCC UL
Model Number: ZRO10

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqms
Price: negotiated
Packaging Details: Flight cases
Delivery Time: 25 days
Payment Terms: T/T 30% Prepayment, T/T 70% before shipment
Supply Ability: 3000 sqms
Contact Now
Detailed Product Description
PCB: 1.6mm Thickness Led: SMD3535
Led Chip: Epistar Cabinet Size: 640*640mm
IC: MBI5124 Power Supplier: G-energy
Connector: Seetronics Warranty: 2 Years

Outdoor P8 640*640mm Led Video Screen Rental 6500nits Die-casting Aluminum​



Real-time Error Detection
Low power consumption
P8 Rental LED Display | Low power,saving energy and money
Silent
P8 Rental LED Display | Silent, no cooling fans
High gray scale, high refresh
High Contrast
Super Slim and Light Weight



Outdoor P8 rental led screen

The special design features of the screens express the unique artistic charm, such as lightness, thinness and so on.
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light.
3) Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle at this range, high brightness, high resolution, clear and non-flash screen image, long service life.
4) First debut of outdoor higher resolution diecasting cabinets
completely aluminum hanging structure eqivalent with heat dissipation
5) 17 Kg/unit,borned for rental application


Application area
Facades of shopping malls, department stores, banks and car dealerships.
Architecture and social projects, information systems in cities.
Outdoor advertising, digital billboards, advertising in big companies
Sports halls, fields, playgrounds.
Airports, bus stations and railway passenger terminals.
Show-business, concerts, festivals, motor shows and other public events.



Feature:
1) LED: well-known international brand, with wide viewing angle, high brightness, little attenuation, good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand. The power t maximum power reserve of 20% the space, the range of voltage fluctuation is less 5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person. The replacement of any cabinet can be done within 50 seconds.



P8 Outdoor led screen Specifications:

Pixel Pitch(㎜) 8
Pixel Density(pixel/㎡) 15625
Pixel Component 1R1G1B
LED Configuration SMD3535
Panel Dimension(W×H)㎜ 320*160
Scan Mode 43105
Cabinet Dimension(W×H)㎜ 640*640
Cabinet Material Die-casting Aluminum
Cabinet Weight(Kg) 17
Brightness(cd/㎡) ≥6500
Color Temperature 3200K-9500K
Viewing Angle(V) 140°
Viewing Angle(H) 140°
Contrast Ratio 125.0006944
Max Power Consumption(w/㎡) ≤800
Ave Power Consumption(w/㎡) ≤320
Operating Power Source AC85~264V(47-63Hz)
Frame Frequency(Frame/S) 60
Refresh Rate(Hz) ≥1200
Gray Level RGB65536Grade
Brightness Adjustment Level 256Grade
Brightness Adjustment Mode Manual/Automatic/Programmable
Control Distance UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp ﹣20℃-﹢50℃
Operating Humidity 10%-90%RH
Protecting Rating Front IP65,Back IP54
MTBF >10000h
LED Life Span >100000h
LED Best View distance 5m-150m
