Product Details:
Payment & Shipping Terms:
|
Module: | 320*320mm | Refresh: | 1920HZ |
---|---|---|---|
Brightness: | >6500nits | Power Supplier: | Meanwell |
IP: | IP65 Front / IP54 Rear | Cabinet Materials: | Steel |
Connnector: | Seetronic | Control System: | Linsn |
Cabinet Size: | Customized 960mm | Support: | Text, Pics, Video |
Warranty: | 2 Years Or Longer | Main Power Cable: | 2.5 Or 4 Square Millimeter |
Support Distance: | CAT5 Within 100m / Fiber >100m | Control: | Synchronous Or Asynchronous(Offline,USB) |
Lamp: | SMD3535 |
Brightness Adjust Automatically IP65 Nationstar Outdoor Fixed Led Display Video Front Access
P10 Outdoor LED Display
ITEM | P10 |
Pixel Pitch(㎜) | 10 |
Pixel Density(pixel/㎡) | 10000 |
Pixel Component | 1R1G1B |
LED Configuration | SMD3535 |
Panel Dimension(W×H)㎜ | 320*160 |
Scan Mode | 1/4 (or 1/2) |
Cabinet Dimension(W×H)㎜ | 960*960/Customized |
Cabinet Material | Iron/Customized |
Brightness(cd/㎡) | ≥6000 ( or ≥7000) |
Color Temperature | 3200K-9500K |
Viewing Angle(V) | 140° |
Viewing Angle(H) | 140° |
Contrast Ratio | 3000:1 |
Max Power Consumption(w/㎡) | 750 |
Ave Power Consumption(w/㎡) | 300 |
Operating Power Source | AC85~264V(47-63Hz) |
Frame Frequency(Frame/S) | 60 |
Refresh Rate(Hz) | ≥1200 |
Gray Level | RGB65536Grade |
Brightness Adjustment Level | 256Grade |
Brightness Adjustment Mode | Manual/Automatic/Programmable |
Control Distance | UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km |
Operating Temp | ﹣20℃-﹢50℃ |
Operating Humidity | 10%-90%RH |
Protecting Rating | IP65 |
MTBF | >10000h |
LED Life Span | >100000h |
LED Best View distance | 8m-300m |
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
