Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 3.91mm | Cabinet Size: | 500*500mm |
|---|---|---|---|
| Materials: | Die-casting | IC: | MBI5124 |
| Refresh: | 1920HZ | Led: | Nationstar |
| Connector: | Seetronics | Flight Case: | 6 Pcs In A Case, Anti-static |
| Weight: | 7.5Kg |
Black face SMD2020 High Grey Scale Led Video Screen Rental Refresh 1920HZ 3.91mm 4.81mm
Advanteges
| ITEM | P3.91 |
| Pixel Pitch(㎜) | 3.91 |
| Pixel Density(pixel/㎡) | 65536 |
| Pixel Component | 1R1G1B |
| LED Configuration | SMD2121/2020 |
| Panel Dimension(W×H)(mm) | 250*250 |
| Scan Mode | 1/16,1/32 |
| Cabinet Dimension(W×H)(mm) | 500*500 |
| Cabinet Material | die-casting aluminum |
| Cabinet Weight Kg | 8 |
| Brightness(cd/㎡) | >1000Nit |
| Color Temperature | 3200K-9500K |
| Viewing Angle(V) | 140° |
| Viewing Angle(H) | 140° |
| Contrast Ratio | 3000:1 |
| Max Power Consumption(w/㎡) | ≤800 |
| Ave Power Consumption(w/㎡) | ≤300 |
| Operating Power Source | AC85~264V(47-63Hz) |
| Frame Frequency(Frame/S) | 60 |
| Refresh Rate(Hz) | ≥1200,≥2880, |
| Gray Level | RGB65536Grade |
| Brightness Adjustment Level | 256Grade |
| Brightness Adjustment Mode | Manual/Automatic/Programmable |
| Control Distance | UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km |
| Operating Temp | ﹣20℃－﹢50℃ |
| Operating Humidity | 10%－90%RH |
| Protecting Rating | IP31 |
| MTBF | ＞10000h |
| LED Life Span | ＞100000h |
| LED Best View distance | 3m-100m |
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Provide unique and professional solutions based on customer's requirement.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
