Events Gold Wire Black face SMD2020 Led Screen Rental Refresh Connector

China Events Gold Wire Black face SMD2020 Led Screen Rental Refresh Connector supplier

Large Image :  Events Gold Wire Black face SMD2020 Led Screen Rental Refresh Connector

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZRI481

Payment & Shipping Terms:

Minimum Order Quantity: 1 qms
Price: negotiation
Packaging Details: Flight case
Delivery Time: 26-30 working days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Led: Black Face SMD2020 Resolution: Ph4.81mm
IC: MBI5124 MBI5252 MBI5024 Lamp: 1R1G1B Epistar
Voltage: 100-240v Brightness: >1000nits
Size: 500*500mm Materials: Die-casting Aluminum
Refresh: 1920 HZ Or 2880 HZ Or 3840HZ Installation: Stacking Hanging

Events use Gold Wire SMD2020 4.81mm Indoor Rental LED Display Refresh 2880HZ Neutrik Connector


Brief introduce:

P1.875, P2, P2.5, P3, P3.91, P4, P4.81, P5, P5.95, P6, P6.25, P6.67, P7.62, P8 and P10 mm pixel pitch led video walls can be utilized for indoor environments;

P3.91, P4. 81, P5, P5.95, P6, P6.25, P6.67, P8, and P10 mm pixel pitch led video walls can be utilized for outdoor environments;

Save Labour cost, Light weight
Different signal resources input such as TV, HDTV, S Video, NTSC/PAL, DVI, VGA, SDI and HD-SDI are acceptable;


1. First-class LED chip: Epistar from Taiwan.
2. With pure golden wire connection in LED Nationstar.
3. Grand A row material for module frame and mask.
4. 4 layers PCB and copper plating thickness > 18mil.
5. Ag alloy solder paster to ensure good soldering on PCB.
6. Stainless steel screws when assembly.
7. Long-term Brightness capacity throughout product lifetime.
8. High Contrast 4000:1

1. Lightweight and slim, Fashion and Easy to assemble:

Fast installation, one cabinet within 5s;

Magnetic lock design for quick positioning and assembly;
Single technician and tool-free installation;

Light weight, 60% space saved for transportation;

Quick Return for Investment, time can reduce to half a year or even shorter;


2. Advanced Dot-by-dot calibration Technology, LED board with flash data storage function:

Enclosed noise-free design, applicable for high end and quiet places;

Snap design mask ensures stableness, flatness and easy maintenance;


Fast: Fast locks on the four edge of the cabinet, only 180 degree rolling will lock the closed two cabinets with high precision. Easy to assemble and disassemble the cabinets, fast, reliable and beautiful, it means true quick-assembling.
Easy: Modular design, easy to assembly and maintain.
Capacity:New design with exclusive cabinet, suitable for P3.91 or more.
Low: Wonderful design for natural heat releasing, no need for fans or air-conditioner, low noise, low structure cost because of the light weight of cabinets, low power dissipation, more cost saved.
Light:Cabinet size 500mmX500mmX80mm, and weight 8kg/pc. Only one hand can hold it, assembly time saved.
Thin: Die-cast aluminum design, high intensity, high tenacity, high precision, unchangeable, 80mm as the thickness, normal cabinet is >130mm.

LED Indoor/Outdoor Video Wall Hiring


The next generation indoor and outdoor LED video walls. Thrill your audience with bright, vivid color display. These high definition panels can be customized to any shape or size wall for your event needs. With this advanced LED technology, possibilities are limitless.


LED Video Wall Hire Solutions


A seamless LED video wall hiring from Ocolour is a turnkey solution to make a high-powered impact at your next event. We offer the high resolution LED video wall rentals for all sorts of events, and other corporate functions. Our LED Screens can be scaled from a small implementation to a large scale venue.



ITEM P4.81
Pixel Pitch(㎜) 4.81mm
Pixel Density(pixel/㎡) 43264
Ratio 4:3 9:6 16:9 any size
LED Configuration SMD2020 Epistar
Panel Dimension(W×H)(mm) 250*250mm
Scan Mode 1/13
Cabinet Dimension(W×H)(mm) 500*500
Power supplier G-Energy
Cabinet Weight Kg 8
Brightness(cd/㎡) >1000Nit
Color Temperature 3200K-9500K
Viewing Angle(V) 140°
Viewing Angle(H) 140°
Contrast Ratio 4000:1
Max Power Consumption(w/㎡) ≤650
Ave Power Consumption(w/㎡) ≤250
Operating Power Source AC85~264V(47-63Hz)
Frame Frequency(Frame/S) 60
Refresh Rate(Hz) ≥1200,≥2880,
Gray Level RGB65536Grade
Brightness Adjustment Level 256Grade
Brightness Adjustment Mode Manual/Automatic/Programmable
Control Distance UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp ﹣20℃-﹢50℃
Operating Humidity 10%-90%RH
Protecting Rating IP31
MTBF >10000h
LED Life Span >100000h
LED Best View distance 3m-100m

Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
