Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification

China Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification supplier
Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification supplier Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification supplier

Large Image :  Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZFO6

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqm
Price: negotiation
Packaging Details: Plywood cases
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 sqms per month
Contact Now
Detailed Product Description
Lamp: Nationstar Maintenance: Rear
Power Supplier: 100-240V Brightness: >7000 Nits
Materials: Steel Control System: Linsn
Control: By Computer Or U-disk Or Wifi Or 3G 4G Or Offline Support Distance: CAT5 <100m , Fiber >100M
Display Content: Texts,pics, Video Refrsh: 1920HZ

Energy Save 7000nits P6 SMD2727 Epistar Outdoor Led Advertising Screen Rosh Wall Mounted

(1) Indoor and outdoor displays;
(2) Backlighting;
(3) Camera flash;
(4) RGB full color LED displays;
Environment Friendly Energy Save Brightness Ajust automatically
Easy maintenance
High reliable quality
Iron cabinet customized size
P6mm led Module Epistar Chip Nationstar Meanwell power supplier
1. Pure-copper environmental flat cable,pure-copper power wire.
2. Ultra bright LED lamp Nationstar, and the best raw materials to made into plastic parts.
3. Chip encapsulation uses pure golden wire to solder, red chip encapsulation uses double pure golden wires to keep stability. Led Chip Epistar, Nichia, Cree
4. The copper silvering trestle.
5. Brushing black lamp with five surface and black gluing to keep the uniformity of screen.
6. Plated signal and power connector.
7. High-end specialized outdoor glue.
8. Front & Rear maintenance Save Labour costs
Adopt grating air convection cooling system,good heat dissapation
Strict waterproof gurantee of quality IP65
Strict quality control, white balance
Strict testing, waterproof testing, Aging testing, White balance test, High /low grey test
Brief info
Meanwell power supplier
3 - 5 years warranty
Waterproof Neutrik connector
Fan cooling system
Epistar Chip Led lamp Nationstar
High brightness >6500nits or 8000nits
Lamp board and driver board separate


It will operate at min Brightness also its save power .

The seamless design improves the display quality.

The replace for modules costs few, without changing the original structure.

This unit cabinet offers a cost-effective display solution for outdoor usage.

The square shape product can be composed from the LED cabinet with the proportion of 16:9 and 4:3.

This LED cabinet only weighs 50kg and with depth of 191mm. That brings the benefits for the transportation.

Featuring high resolution and high brightness, it can keep high contrast level even in strong sunlight.


RGB outdoor advertising led screen real pixel can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.


Currently P6 outdoor advertising led screen is the most popular in outdoor digital media application. It has advantages like customized display sizes, high definition, friendly user interface and multi-functional control methods.


Full color P6 outdoor led video screens can satisfy all kinds of demands of outdoor commercial digital media. And it is hotseller in past few years. Also new ideas are used onto it like AR, Interactive....


P6 Outdoor Fixed LED Display

Pixel Pitch(㎜) 6
Pixel Density(pixel/㎡) 27777
Pixel Component 1R1G1B
LED Configuration SMD2727 Nationstar
Panel Dimension(W×H)㎜ 192*192
Scan Mode 1/8
Cabinet Dimension(W×H)㎜ 768*768 / Customized
Cabinet Material Iron / Aluminum
Brightness(cd/㎡) ≥6500
Color Temperature 3200K-9500K
Viewing Angle(V) 140°
Viewing Angle(H) 140°
Contrast Ratio 3000:1
Max Power Consumption(w/㎡) 1000
Ave Power Consumption(w/㎡) 380
Operating Power Source AC85~264V(47-63Hz)
Frame Frequency(Frame/S) 60
Refresh Rate(Hz) ≥1200
Gray Level RGB65536Grade
Brightness Adjustment Level 256Grade
Brightness Adjustment Mode Manual/Automatic/Programmable
Control Distance UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp ﹣20℃-﹢50℃
Operating Humidity 10%-90%RH
Protecting Rating IP65


Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.Energy Save Outdoor Led Advertising Screens Wall Mounted RoSH Certification
