8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color

Good quality Led Video Screen Rental for sales
Good quality Led Video Screen Rental for sales
Zhongyi is a trusted and professional supplier I have ever met.Thanks so much for your help to deal with my last urgent order.

—— Michael

I have bought twice from Andy, and the quality is great. Hope you guys can be better and better.

—— Dinesh

Good service!At one time,my flight case have crashed when shipping, thanks for doing maintenance and renew our screens.

—— Mohammed

I'm Online Chat Now

8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color

China 8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color supplier
8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color supplier 8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color supplier

Large Image :  8000 Nits P10 Front Open DIP LED Display 960 * 960 MM 1R1G1B Full Color

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZFO10

Payment & Shipping Terms:

Minimum Order Quantity: 1 sqms
Price: negotiation
Packaging Details: Plywood cartons
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 sqms per month
Contact Now
Detailed Product Description
Material: Aluminum Module: 320*160mm
Cabinet Size: 960*960mm Scan: 1/2
Cabinet Weight: 45kg Per Sqm Contrast: 3000:1
Controller System: Linsn Control: By Computer Or U-disk
Installtion: Hanging / Stacking / In Wall Power Supplier: Meanwell

8000nits P10 Front Open DIP LED Display 960*960mm 1R1G1B Full color Video Display

Brief introduction:

•Auto brightness adjustment.


•High refresh rate & High gray.



•Energy saving & Long life span.



•High resolution & Vivid image.


•Durability & Flatness.

Advantages:
1. P10 High reliable full colour outdoor DIP led display, have the size of 960mm and 960mm or others.
2. The square shape product can be composed from the LED cabinet with the proportion of 16:9 and 4:3.
3. This LED cabinet only weighs 40kg and with depth of 100mm. That brings the benefits for the transportation.
4. The seamless design improves the display quality.
5. Featuring high resolution and high brightness, it can keep high contrast level even in strong sunlight.
6. The replace for modules costs few, without changing the original structure.
7. This unit cabinet offers a cost-effective display solution for outdoor usage.
8. Lamp board and driver board separate

Feature
1. New design for advertising,in the past,all the advertisement is standing,while now all the advertisment can be mobile,therefore,it can have better advertisment effect.Instead of having fixed outdoor video displays in several locations,a mobile LED display installed on a truck that you can park in different strategic points of the city,at peak times of each day,in addition,if you are an event management company and need to have a led display move anywhere,a truck-mounted led display would be the perfect answer.

2. Portable led display.Owing to the truck,it is very easy to move from one place to another.

3. Our LED display can be installed in different areas all over the world.Low temperature as -20℃ and high temperature as +60℃,high humidity and high salty air enviroment such as seaside,out cabunet is moisture-proof and salt-proof.

4. High brightness DIP LED is widely used for mobile truck led display with weatherproof design,so can be used outdoor with cute weather.Meanwhile,vivid color performance and high conformity would bring an excellent display effect for the event.

Introductions:
Currently P10 High reliable full colour outdoor DIP led display is the most popular in outdoor digital media application. It has advantages like customized display sizes, high definition, friendly user interface and multi-functional control methods.

P10 Outdoor fixed led display can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.
No Tool needed Front Access
Module 320*320mm
Aluminum Cabinet
1R1G1B Full color 14-16 bits
Modular Panels
Meanwell Power supplier
3-5 years Warranty
Good Waterproof, Anti-UV
Driver board and Lamp board separate
Long lifetime, Easy to do maintance

P10 Outdoor DIP Led Screen
ITEM Ph10
Pixel Pitch(㎜) 10mm
Pixel Density(pixel/㎡) 10000
PCB 1.6mm Thickness
MBI MBI5124 MBI5024
Panel Dimension(W×H)㎜ 320*160
Scan Mode 1/4 1/2
Cabinet Dimension(W×H)㎜ 960*960
Cabinet Material Iron/Customized
Brightness(cd/㎡) ≥6500
Color Temperature 3200K-9500K
Viewing Angle(V) 140°
Viewing Angle(H) 140°
Contrast Ratio 3000:1
Max Power Consumption(w/㎡) 800
Ave Power Consumption(w/㎡) 350
Operating Power Source AC85~264V(47-63Hz)
Frame Frequency(Frame/S) 60
Refresh Rate(Hz) ≥1920
Gray Level RGB65536Grade
Brightness Adjustment Level 256Grade
Brightness Adjustment Mode Manual/Automatic/Programmable
Control Distance UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp ﹣20℃-﹢50℃
Operating Humidity 10%-90%RH
Protecting Rating IP65
MTBF >10000h
LED Life Span >100000h
LED Best View distance 8m-300m


Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
