Permanent 3 In 1 Led Video Wall Screen 5V 60 A High Brightness Smart Control

China Permanent  3 In 1  Led Video Wall Screen 5V 60 A High Brightness Smart Control supplier

Large Image :  Permanent 3 In 1 Led Video Wall Screen 5V 60 A High Brightness Smart Control

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZFI3

Payment & Shipping Terms:

Minimum Order Quantity: 1 squaremeter
Price: negotiation
Packaging Details: Flight case or Plywood
Delivery Time: 26-30 working days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Feature: P3 HD Led Video Wall Power: 5V 60 A
LED: Nationstar Control: Wifi, Ipad, Computer, U-disk
Warranty: 3 Years Brightness: 1000-1500nits
Design: No Noise Power Supplier: Meanwell

Permanent 1080p RGB 3 in1 Led Wall Video Display screen in Church, Meeting

Quick details
P3 led video wall screen customized size
Moduler panels make a big size screens as you like
Cabinet size 768*768mm or customized (720p,1080P)
Nationstar led lamp SMD2020
MBI Ic from Taiwan
Meanwell power supplier 5V 60A
CE & UL certifications
Brightness:>1000nits
Magnetic front maintenance led screen

Classical design and natural tech., reliable quality and great performance.

Seamless connecting tech., screen flatness error <0.1mm.

Patented mask, eliminating the dark spots, improving consistency and viewing angle.

PCB 1.6mm Thickness 4 layers


Feature
1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.

Low Cost of Splicing
With an aspect ratio of 16:9, panel size is carefully designed so that the HD LED display can be assembled quickly and efficiently into the common display ratio of 4:3 or 16:9

Indoor fixed led screen has many kinds of installation, like front open design, magnetic led panel design. It can be used all kinds shopping malls, night clubs, conference and so on.

P3 Indoor Led Screen
ITEM
Ph3
Pixel Pitch(㎜)
3mm
Pixel Density(pixel/㎡)
111111
Pixel Component
1R1G1B
LED Configuration
SMD2020 Epistar
Panel Dimension(W×H)㎜
192*96 192*192
Scan Mode
1/32
Cabinet Dimension(W×H)㎜
768*768mm
Cabinet Material
Steel
Cabinet Weight(㎏)
50KG per sqm
Brightness(cd/㎡)
≥1000( Color Temperature6500K)
Color Temperature
3200K-9500K
Led lamp Nationstar
Contrast Ratio
4000:1
Max Power Consumption(w/㎡)
1200
Ave Power Consumption(w/㎡)
480
Operating Power Source
AC85~264V(47-63Hz)
Frame Frequency(Frame/S)
60
Refresh Rate(Hz)
≥1920
Gray Level
RGB65536Grade
Brightness Adjustment Level
256Grade
Brightness Adjustment Mode
Manual/Automatic/Programmable
Control Distance
UTP<100m;Muti Mode Fiber<500m;Single Mode Fiber<10Km
Operating Temp
﹣20℃-﹢50℃
Operating Humidity
10%-90%RH
Protecting Rating
IP34
MTBF
>50000h
LEDLife Span
>100000h
LEDBest View distance
5m-150m


Pre-sale service:
1. Reply enquiries in 16 hours.
2. Provide unique and professional solutions based on customer's requirement.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
