Large Scale P31.25 Grid Outdoor Full Color Led Fixed Display 6000 Nits
-
-
Large Image :
Large Scale P31.25 Grid Outdoor Full Color Led Fixed Display 6000 Nits
|
Product Details:
| Place of Origin: |
Shenzhen, China |
| Brand Name: |
Zhongyi |
| Certification: |
CE / RoHS / FCC / ETL / TUV |
| Model Number: |
ZF31 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 squaremeter |
| Price: |
negotiation |
| Packaging Details: |
Plywood cartons |
| Delivery Time: |
15-18 days after received prepayment |
| Payment Terms: |
30% T/T prepayment, 70% T/T balance before shipment |
| Supply Ability: |
3000 squaremeters per months |
|
Detailed Product Description
| Support: |
Video Pictures Texts |
Resolution: |
1024 |
| Warranty: |
2 Years Or Longer |
Work Temprature: |
-35℃ -- -80℃ |
| Brightness: |
6000nits |
Control: |
Brightness Adjust |
| IC Brand: |
MBI |
Control System: |
Ydea |
| Maintenance: |
Front & Rear Maintenance |
Large Scale P31.25 Grid Led Curtain Outdoor Fixed Led Display 6000 nits in -35℃
Brief info:
Reunion Connector
Low temperature power supplier
Great reliable quality
-35℃ -- -80℃
80% heat sinking IP67
Signal, power supply stability, the use of safe and reliable
Efficient and stable, high reliability, long service life
No fan design, low temperature operation, quiet no noise
Ultra-thin box, easy to transport, installation and maintenance
Support front and rear maintenance, installation more convenient
Low power consumption, low heat, energy saving and environmental protection
Fast maintenance
Patented design for 3 minutes/sqm
Easy to achieve front / rear maintenance
Special only led Grid Screen
Steel weight 10KG/sqm only, equal 15% of traditional outdoor led screen steel Cabinet
Transparency 40%-80%
Look like Screenless
Quick installation
Finish installation 10 seconds per sqm
Quick introduction:
Cost savings of Air conditioner
Cost savings 80% of maintain operation
Cost savings 70% of electricity
Cost savings 70% of steel structure
Cost savings 80% of labour
Cost savings 75% of transportation
Specification parameter P31.25 outdoor Led Curtain Fixed led Display
| Tube color | Specifications | Indicators (typical values, specific to selected lamps) |
| R | domestic | Wavelength: 618-630nm, brightness 870mcd (20mA) |
| G | domestic | Wavelength: 518-538nm, brightness 1680mcd (10mA) |
| B | domestic | Wavelength: 460-480nm, brightness 380mcd (10mA) |
| Product model | 31.25mm-31.25mm |
| Horizontal spacing(mm) Vertical spacing(mm) | 31.25mm 31.25mm |
| Pixel composition | DIP346 |
| Resolution (dot/㎡) | 4096 |
| Unit cabinet dots | 1024 |
| Pixel per Unit(dots) | 32(W)x32(H) |
| Color Grayscale (Bit) | 14 |
| Brightness(CD/㎡) | ≥6000cd |
| Contrast | 1:1600 |
| Color temperature | 6500-9300k |
| (Brightness adjust) | 0-255 |
| Horizontal viewing angle(°) Vertical viewing angle(°) | ≥110° ≥50° |
| Support | DVI HDMI |
| Max Consumption(W/㎡) | 450 |
| Average power consumption(W/㎡) | 135 |
| Unit cabinet Weight (kg/pcs) | 10.0 |
| Cabinet Weight (kg/㎡) | 20.0 |
| Frame Weight (kg/㎡) | 8.0 |
| Unit cabinet thickness (cm) | 6.7 |
| Frame thickness (cm) | 6.0 |
| Installation thickness (cm) | 12.7 |
| Strips width(mm) | 9.8 |
| Transparent Rate(%) | 40% |
| Frame rate(HZ) | 60 |
| Pixel uncontrol rate | ＜1/10000 |
Pre-sale service:
1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
