Real pixel P12 Outdoor Led Video Screen Advertising Display Billboard RGB

China Real pixel P12 Outdoor Led Video Screen Advertising Display Billboard RGB supplier
Real pixel P12 Outdoor Led Video Screen Advertising Display Billboard RGB supplier Real pixel P12 Outdoor Led Video Screen Advertising Display Billboard RGB supplier

Large Image :  Real pixel P12 Outdoor Led Video Screen Advertising Display Billboard RGB

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Zhongyi
Certification: CE / RoHS / FCC / ETL / TUV
Model Number: ZF12

Payment & Shipping Terms:

Minimum Order Quantity: 1 squaremeter
Price: negotiation
Packaging Details: Plywood cartons
Delivery Time: 15-18 days after received prepayment
Payment Terms: 30% T/T prepayment, 70% T/T balance before shipment
Supply Ability: 3000 squaremeters per months
Contact Now
Detailed Product Description
Lamp: 1R1G1B Real Pixel PCB: 1.6mm Thickness
Connector: Seetronic Warranty: 2 Years Or Longer
Power Supplier: Meanwell Brightness: 6500nits
Voltage: 5V 40A Weight: 55kg Per Sqm
LED: 1R1G1B

Real pixel P12 Epistar Video Outdoor Led Video Screen Advertising Display Billboard



P12 Real pixel Vivid Video Outdoor led screen
Specifications
Epistar Chip led lamp DIP346

PCB 1.6mm thickness PCB 4 layers

Meanwell power supplier

2 Years warranty



1. Ultra bright LED lamp Nationstar, and the best raw materials to made into plastic parts.
2. Chip encapsulation uses pure golden wire to solder, red chip encapsulation uses double pure golden wires to keep stability. Led Chip Epistar Nichia Cree
3. The copper silvering trestle.
4. High-end specialized outdoor glue.
5. Brushing black lamp with five surface and black gluing to keep the uniformity of screen.
6. Plated signal and power connector.
7. Pure-copper environmental flat cable,pure-copper power wire.

High Brightness, Brightness adjust automatically

Meanwell Power supplier, Seetronic Connector



P12 specifications:

1. LED cabinet of die cast aluminum material, strong and good for hanging,ground install

2. LED lamps of DIP can be optional for Nationstar or other middle level quality, meet different quality request

3. High brightness above 5000nits, can well display color and photo,video display for whole strong sunshine day.

4. With avaiation power and data connector cables, keep screen working more stable and reliable.



Feature

High quality LED chip and high anti-static electricity capacity.

Large viewing angle and smooth displaying provide excellent visual effect from every angle.

The integration of lamp and driving IC, together with with the multi-circuit structure, achieves evenly-distributed current, low power consumption and fast heat dissipation.

Ultra-high brightness, low attenuation, high reliability and weather ability.



P12 Waterproof outdoor led video screen can be hanging, Stacking, Installation into the wall and so on. Also It can be designed as front open, front access screens to make the maintanance easy.



Specification parameter

P12 outdoor led video screen 1R1G1B
Module size 192*192mm
Pixel pitch 12mm
Pixel density 6944dots/m2
Pixel configuration DIP346 1R1G1B
Display color Full color
Warranty 2 years or longer
Led specification Φ3ellipse
IC MBI5124
Cabinet
Dimension 960mm*960mm*170mm
Quantities of module 25pcs
Power supply 4pcs
Thermal discharge Fan*2pcs
Total weight 60kg
Best viewing angle 10-150m
Temperature Storage: -35°C~+85°C
Working: -35°C~+85°C
Thickness 17cm can adjustable
Remarks: cabinet size can changed, upon project need.
Power
Working voltage AC220V/110V±10%
Average power consumption 250-400W
Max. Power consumption ≤1000W/sqm
Current ≤20mA(single LED)
Control system
CPU Pentium4 or above
Type LINSN
Operating system WIN98/2000/NT/XP
Control method Synchronization&Asynchronization




Pre-sale service:

1. Reply enquiries in 16 hours.
2. Market research and forecast for customer.


In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.


After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
